Honeywell MCSS-A

Overview :

These fast acting, reliable, and extremely easy to install sensors have a solid-state output with an adjustable or fixed trip point (setpoint). These current switches should be used in applications in which a “Go/No Go” current switch is required.

Features :

Solid or split core switches with fixed or adjustable trip points
Very low operating trip points
LED status indication
Integral DIN rail mounting flange
Accepts up to a 350 MCM (17.3 mm) cable
Operates up to 250 continuous amps
RoHS and WEEE Compliant
Limited 5 year warranty

Product Specifications :

Application: Great for monitoring fans, pumps, motors, compressors, or other electrical equipment
Dimensions (in.): 1.991 in. high x 2.5 in. wide x 0.942 in. deep
Dimensions (mm): 51 mm high x 63 mm wide x 24 mm deep
Frequency: 50 H; 60 Hz
Approvals, Underwriters Laboratories Inc.: Approved
Operating Humidity Range (% RH): 0 to 95% RH, non-condensing
Operating Temperature Range (F): -22 to 140oF
Operating Temperature Range (C): -30 to 60oC
